RC4WD 1/14 SCALE EARTH MOVER 870K HYDRAULIC WHEEL LOADER – VV-JD00031
The RC4WD Earth Mover 870K is a professionally assembled 1/14-scale hydraulic wheel loader built for experienced RC operators who want a large, metal-heavy construction machine with functional hydraulics, articulated steering and realistic drivetrain architecture. With CNC-machined metal parts, a molded steel bucket, full-metal axles and a brushless hydraulic system, this is a serious scale machine rather than a basic hobby-grade loader.
HEAVY-DUTY CONSTRUCTION
- CNC-machined metal parts
- Molded steel bucket
- Optimized steel hydraulic system
- Full-metal axles
- Planetary gearbox built into the wheels
- Scale ABS interior and operator station
- Powder-coated yellow finish with white cab
- Massive 29.5-25L-5 loader tires
HYDRAULIC SYSTEM
- Reliable hydraulic valve and adjustable pump
- Brushless hydraulic system
- 40A brushless ESC with BEC
- Heavy-duty nylon hydraulic hoses: 4.5 mm OD / 2.5 mm ID
- Steel-machined oil pump: 45 × 30 × 15.5 mm
- Published operating oil pressure: 20 bar / 290 psi
- Maximum bucket force: 70 kg / 154 lb
DRIVETRAIN & CONTROL
- 2-speed full-metal transmission
- Gear ratios: 1:16 and 1:4
- Full-metal axles
- Wheel-mounted planetary reduction
- 2.4GHz radio system
- LiPo cutoff
- Realistic non-functional disc-brake detail
DIMENSIONS & CAPACITY
- Scale: 1/14
- Length: 741 mm / 29 in
- Width: 276 mm / 11 in
- Height: 276 mm / 11 in
- Wheelbase: 284 mm
- Maximum bucket height: 461 mm / 18 in
- Maximum bucket up/down angle: 46–64°
- Maximum bucket left/right angle: 38°
- Dead weight: 20.5 kg / 45 lb
- Total mass load: 32 kg / 70 lb
- Maximum bucket force: 70 kg / 154 lb
POWER REQUIREMENTS
- 3S LiPo battery
- RC4WD documentation references a 6500mAh 11.1V 20C pack for this platform
- Compatible LiPo charger
- Radio batteries as required by the supplied transmitter
- AW ISO 32 hydraulic oil for the hydraulic system
WHAT'S INCLUDED
- 1x RC4WD 1/14 Earth Mover 870K Hydraulic Wheel Loader – Yellow/White
- 2.4GHz radio system
- 1/14 loader LED lighting system
IMPORTANT OPERATING NOTES
- This product is intended for experienced RC users.
- Inspect all hardware and screws after shipping and before first operation.
- Use thread lock sparingly on metal-to-metal fasteners where appropriate.
- Do not overtighten small fasteners or hydraulic fittings.
- Do not allow the hydraulic system to overheat during extended operation.
- Check hoses, fittings and pump connections for leaks before working under load.
- Keep the machine's operating pressure within the manufacturer's specified hydraulic range.
GASHEAD RC OWNER NOTE
The 870K is a large, heavy hydraulic model. Before the first serious work session, perform a full mechanical and hydraulic inspection: check wheel hardware, axle mounting, transmission engagement, hose routing, pump fittings, loader-arm pins and bucket linkage. A machine in this weight class can place significant loads on its drivetrain and hydraulic circuit, so careful setup and regular inspection matter far more than they do on a lightweight crawler.
SKU: VV-JD00031
